Compact Classic Series

Overview

Compact for easy installation indoors and in tight spaces

Perfect for new homes, the Compact Classic is a price conscious gas ducted heating system, a no fuss solution that's easy to install. Two models to choose from:

  • CC3202IN, 3.5 star 20 kW
  • CC330IN, 3.3 star 30 kW

Features

  • excellent value for money
  • three speed fan
  • up to 3.5 star energy rating
  • compact and splittable
  • three year parts and labour warranty

Read More

Product Details

Indicative pricing
An indicative total installed cost (including; furnace, controller, ducting, outlet, return grilled and installation) for a small home (80-180 m2 with 6-10 outlets) is $7000-$10,000 and for a larger home (180-20 m2 with 11-15 outlets) is $11,000-$14,000.



  • Internal installations only (no lay down kit)
  • Natural Gas connections only
  • Not compatible with ZonePlus

Technical Specifications

Model and order codes
  • CC3202IN, 3.5 star 20 kW
  • CC330IN, 3.3 star 30 kW
Airflow L/s @ 100Pa ESP

CC3202IN = 500
CC330IN = 940

Net weight

CC3202IN = 57 kg
CC330IN = 71 kg

Dimensions

Compact Classic line drawing with dimensions

Networker controller compatibility

A Network controller can be used with a Compact Classic if an additional board is added—B062214 539 interface. Please note, full Networker functions are not available due to limitations with the control board on the Compact Classic.

Market release

2016
